Our premium 3 way ball valve represents the pinnacle of flow control technology, engineered for complex industrial applications requiring precise flow diversion, mixing or distribution. Crafted from high-grade CF8/CF8M stainless steel, this valve offers exceptional corrosion resistance and durability in demanding environments. The innovative high platform design allows easy integration with pneumatic actuators for automated operation, while maintaining the option for manual control. With multiple connection types including flanged, NPT and true union configurations, this versatile valve suits various piping systems. Ideal for water treatment, petroleum refining, and chemical processing applications where reliable performance under high pressure and temperature conditions is essential.

Features:

Constructed from corrosion-resistant CF8/CF8M stainless steel
High platform design for easy actuator mounting
Optional pneumatic actuator for automated operation
Three-way configuration for flow diversion and mixing applications
Multiple connection types: Flanged, NPT, True Union
Fire-safe design available
Low operating torque for efficient performance
Suitable for high-pressure and high-temperature applications
Compliant with international quality standards

Advantages:

Advantage	Description
Superior Corrosion Resistance	CF8/CF8M stainless steel construction withstands aggressive media and environments
Automation Ready	High platform design enables easy integration with pneumatic actuators
Versatile Flow Control	Three-way design enables multiple flow patterns for complex system requirements
Multiple Connection Options	Various end connections ensure compatibility with different piping systems
High Pressure Capability	Robust construction handles pressures up to 900 PSI
Temperature Resilience	Performs reliably in temperatures from -22°F to 284°F
Low Maintenance	Quality materials and design ensure long service life with minimal maintenance

Specifications:

Attribute	Value(s)
Size Range	DN15 - DN80 (½" - 4")
Body Material	CF8/CF8M Stainless Steel
Connection Types	Flanged, NPT, True Union
Operation Options	Manual Lever or Pneumatic Actuator
Media	Water, Oil, Gas, Chemicals
Temperature Range	-22°F to 284°F (-30°C to 140°C)
Pressure Rating	200 PSI, 500 PSI, 900 PSI
Seal Materials	PTFE, EPDM, NBR, FPM, FKM
Design Standard	API, ANSI, ISO
Warranty	2 Years
